Description Technical Specifications: Rated Power: 5000W Voltage: 230V AC Surge Power: 5000VA Efficiency: 90-93% Transfer Time: 20ms for home appliances Waveform: Pure sine wave Battery: Battery Voltage: 48V DC Floating charge Voltage: 5V DC Overcharge Protection: 66V DC Important Note: When using this inverter with Lithium batteries, care should be taken to correctly size the bank, taking into account the maximum current which this inverter requires VS what the battery can deliver. Maximum continuous current per inverter = -110A, max. peak current = -220A (depending on battery SOC / terminal voltage). Solar Charger & AC Charger: Max PV Array Power: 4000W Max PV Array VOC: 145V DC MPPT Range @ Operating Voltage: 60 ~ 115V DC Max Solar Charger Current: 80A Max AC Charger: 60A Physical: Dimensions(D x W x H): 100 x 300 x 440mm Weight: 13.5kgs Communication Interface: USB / RS232 / RS485 / Bluetooth / Dry-contact Environment: 5% to 95% Relative Humidity (Non-condensing) Operating temperature:-10°C to 55°C Storage Temperature: -15°C to 60°C
